A variety of CAM files can be generated; these may be Gerber, Drill, Pick & Place, Routing and etc. The files are then used for the fabrication and assembly of the finished designs.

Designs of simple two or four layer PCB's can be reproduced from an existing board. Plated through hole designs can also be upgraded to a surface mounted design.

Schematic symbols and PCB footprints are created for customer designs if not available in our libraries as new devices are being introduced regularly by component manufacturers.

Committed to creating quality designs we have processed thousands of successful jobs. Throughout the PCB design we consider all the latest design requirements to deliver our clients layouts that ensure a smooth transition through the fabrication process. The end result is reliability and cost efficiency for our clients.

Our designers have covered all aspects of PCB design:

• Single sided to complex fine line multi layer designs
• Rigid, Flexible and Rigid-Flex PCB's
• Analog, high speed Digital
• RF and Switch-mode power supply
• Double sided high density SMD loadings
• Fine pitch SMD and BGA layouts

• Mixed, SMT and PTH technology
• EMC and EMI Design consideration
• Complying with IPC2221A Standards
• Design for Manufacturability and Testability
• Panelisation of Job
• Design rule checks are adapted to each individual job

The schematic layout can be undertaken at any stage of development from sketches or CAD files. Electric rule checks are applied to the schematics and all errors are rectified. The schematics are then approved by the customer before the next stage is undertaken.
